Webasto thermo top evo Installation Documentation

Audi A1
Ident. No.: 1324052C_EN Status: 06.10.2016 © Webasto Thermo & Comfort SE
7
Diesel only
1 Copy hole pattern, 7mm dia. hole
Hole for
fuse holder
All vehicles
1 Passenger compartment relay and
fuse holder
2 PWM GW socket
3 Angle bracket
4 M5x16 bolt, large diameter washer
[2x], nut
Premount-
ing passen-
ger
compart-
ment relay
and fuse
holder
1 25A fuse F4
2 PWM GW
3 Relay K1
Installing
passenger
compart-
ment relay
and fuse
holder
5
10
10
6
4
2
3
1
7
1
3
2
