Slide 10 mm dia. corrugated tube 1 on to fuel
line of fuel standpipe
3. Check the position of
the components; adjust if necessary. Check
that they have freedom of movement.
2 Hose section, 10 mm dia. clamp [2x]
Connect-
ing meter-
ing pump
51
1
2
3
