VW Golf VII / Golf VII Sportsvan / Passat and Skoda Superb
Diesel
Align spring clip 1 [5x] as shown.
Aligning
hose
clamps
All vehicles
1 Heater wiring harness connector [2x]
Installing
wiring har-
ness
1 Original vehicle stud bolt, M8 flanged
nut [2x each]
2 Bracket
Installing
heater
1 Stud bolt of bracket, large diameter
washer, M8 flanged nut
Installing
heater
43
1 11
1 1
44
11
45
1
1
2
46
1
