Webasto thermo top evo

Ident. No.: 1325133C_EN Status: 09.06.2017 © Webasto Thermo & Comfort SE
33
VW Golf VII / Golf VII Sportsvan / Passat and Skoda Superb
Attach fuel line 1 for tension relief at an ap-
propriate point.
2 FuelFix installed
Securing
fuel line
FuelFix Installation for Passat/
Superb TDI Front-Wheel Drive
X =
Preparing
drilling tem-
plate
Work steps F1 and F2.
1 Fuel tank sending unit
2 Position 19mm dia. drilling template
as shown
3 2mm dia. centre hole
F
Copying
hole pattern
Work step F3.
1 Hole made with provided drill
Hole for
FuelFix
88
1
2
89
X
1 2
19
3
90
Ø2
max. 1,5
91
1
