You will find an identification mark on the outside top right corner of the page in question to provide you with a quick overview
of the individual working steps.
Ident. No.: 1325133C_EN Status: 09.06.2017 © Webasto Thermo & Comfort SE
7
VW Golf VII / Golf VII Sportsvan / Passat and Skoda Superb
Mechanics Electrics Coolant Circuit Combustion Air Fuel Exhaust Gas Software
Special features are highlighted using the following symbols:
Reference to the manufacturer's vehicle-spe-
cific documents.
Reference to specific installation instructions
of Webasto components
(demonstrated with the example of the FuelFix).
Reference to general installation instructions
of Webasto components.
Tightening torque according to the manu-
facturer's vehicle-specific documents.
Nm
!
Specific risk of damage to components.
Specific risk due to electrical voltage.
Specific risk of fire or explosion.
Reference to a special technical feature.
The arrow in the vehicle
icon indicates the
position on the vehicle
and the viewing angle.
Information on Validity
This installation documentation applies to VW / Skoda / petrol and diesel vehicles - for validity, see pages 1 to 4 - from model
year 2013 and later, assuming technical modifications to the vehicle do not affect installation, any liability claims excluded.
Depending on the vehicle version and equipment, modifications may be necessary during installation with respect to this
‘installation documentation’.
Vehicle and engine types, equipment variants and other specifications not listed in this installation documentation have not
been tested. However, installation according to this installation documentation may be possible.
Technical Information
Explanatory Notes on Document
Special Tools
• Hose clamp pliers for auto-tightening hose clamps
• Hose clamp pliers for Clic hose clamps of type W
• Automatic wire stripper, 0.2 - 6mm²
• Crimping pliers for cable lug / tab connector, 0.5 - 6mm²
• Torque wrench for 2.0 - 10 Nm
• Hose clamping pliers
• Metric thread-setter kit
• Deep-hole marker
• Webasto Thermo Test Diagnosis with current software
Dimensions
• All dimensions are in mm.
Tightening torque values
• Tighten bolt connections in accordance with manufacturer's instructions or in accordance with state-of-the-art-technology.
