VW Golf VII / Golf VII Sportsvan / Passat and Skoda Superb
Ident. No.: 1325133C_EN Status: 09.06.2017 © Webasto Thermo & Comfort SE
5
Table of Contents
Necessary Components
Webasto Individual Option
Installation Instructions
Information on Total Installation Time
Validity 1
Necessary Components 5
Installation Instructions 5
Information on Total Installation Time 5
Information on Operating and Installation Instructions 6
Information on Validity 7
Technical Information 7
Explanatory Notes on Document 7
Preliminary Work for Golf VII / Golf VII Sportsvan 8
Preliminary Work for Passat 8
Preliminary Work for Superb 9
Heater Assembly Installation Location 9
Preparing Electrical System 10
Electrical System 12
Air-Conditioning Control 13
Heater Control Elements for Golf VII 13
Heater Control Elements for Sportsvan 15
Passat/ Superb Heater Controls 16
Preparing Installation Location 19
Installing Heater Assembly 20
Fuel 23
FuelFix Installation for TSI 27
FuelFix Installation for Golf VII/ Golf VII Sportsvan TDI 30
FuelFix Installation for Passat/ Superb TDI Front-Wheel Drive 33
Installing FuelFix for Superb TDI 4x4 36
TSI Coolant Circuit 40
Coolant Circuit for TDI Front-Wheel Drive 46
Coolant Circuit for Superb 2.0 TDI 4x4 and 1.6 TDI 50
Final Work 54
FuelFix Template for TSI 55
FuelFix Template for TDI Golf VII/ Sportsvan/ Superb 4x4 56
FuelFix Template for TDI Passat/ Superb Front-Wheel Drive 57
Description Order No.:
Delivery scope of VW / Skoda / Seat / petrol 2013 TT-Evo 1325108B
Delivery scope of Golf / Passat / Superb diesel 2013 TT-Evo 1325106B
Additional kit ‘Webasto Standard’ for A/C control of VW / Skoda / Seat MQB
with Climatic and Climatronic
or
Additional kit ‘Webasto Comfort’ for A/C control of VW / Skoda / Seat MQB with Climatronic
1325085_
1325012_
In case of Telestart, heater control, as well as indicator lamp in consultation with end customer In accordance with price list
In case of installation of MultiControl CAR - MultiControl installation frame 9030077_
Description Order No.:
Webasto Individual Auxiliary Heating additional kit 1320077_
Webasto Individual Quick additional kit 9030826_
Webasto Individual Select additional kit 9030828_
Arrange for the vehicle to be delivered with the tank only about ¼ full.
The installation location of the push button in case of Telestart or ThermoCall should be confirmed with the end customer.
Depending on the space required and the vehicle manufacturer's instructions, we recommend the use of a vehicle battery
with a higher electrical capacity.
Ensure sufficient distance from original vehicle components when installing the premounted heater assembly, correct if nec-
essary.
Golf VII / Golf VII Sportsvan
Pictures used for the installation steps are of a 1.6TDI vehicle. Deviations are documented separately!
Passat / Superb
Pictures used for the installation steps are of a 2.0TDI (2WD) vehicle. Deviations are documented separately!
The total installation time includes the time needed for mounting and demounting the vehicle-specific components, the heat-
er specific installation time and all other times required for the system integration and initial start-up of the heater.
The total installation time may vary for vehicle equipment other than provided.
