Webasto thermo top evo

Ident. No.: 1325133C_EN Status: 09.06.2017 © Webasto Thermo & Comfort SE
27
VW Golf VII / Golf VII Sportsvan / Passat and Skoda Superb
Cut 10mm dia. corrugated tube to length
by 130mm. Pull fuel line and metering
pump wiring harness into 130mm dia. cor-
rugated tube 1.
2 Metering pump wiring harness, con-
nector X7 mounted
3 Fuel line of heater, hose section, 10
mm dia. clamp [2x]
4 Cover cap inserted
Connect-
ing meter-
ing pump
FuelFix Installation for TSI
X =
Preparing
drilling tem-
plate
Work step F1.
Remove sticker 2, will finally be fixed on
again in a new position.
1 Fuel tank sending unit version 1
3 Fuel tank sending unit version 2
F
Moving
sticker
Next work steps are shown on a fuel tank
sending unit version 1.
Work steps F2 and F3.
1 Fuel tank sending unit version 1
2 Position template with outer dia.
d
a
= 22mm at the markings.
3 Hole pattern
4 Hole made with provided drill
F
Copying
hole pat-
tern, drilling
hole
64
1 2
3
4
65
X
2
2
66
1
3
67
3
4
1
2
3
