Webasto thermo top evo

Ident. No.: 1325133C_EN Status: 09.06.2017 © Webasto Thermo & Comfort SE
24
VW Golf VII / Golf VII Sportsvan / Passat and Skoda Superb
Open original vehicle pass through 1 as
shown, insert corrugated tube with fuel
line and metering pump wiring harness 3.
2 Clip-type cable tie, original vehicle
hole
X =
Routing
corrugated
tube
through
original ve-
hicle pass
through
Version 1
1 Detach retaining clip from hole (if
present)
2 Remove cover cap (will be remounted
later)
Preparing
installation
location of
metering
pump
Insert M6x20 bolt 1 through opening 2 into
hole.
Preparing
installation
location of
metering
pump
1 M6x25 bolt, flanged nut
2 Support angle bracket
3 Hose section, 10mm dia. [2x each]
4 Perforated bracket
5 Metering pump mount
6 Metering pump
Premount-
ing meter-
ing pump
52
1
2
1
X
1
2
53
1
2
54
1
2
55
1 2
6 5 4
3
3
