Webasto thermo top evo

Ident. No.: 1325133C_EN Status: 09.06.2017 © Webasto Thermo & Comfort SE
35
VW Golf VII / Golf VII Sportsvan / Passat and Skoda Superb
Work step F6.
1 Fuel line
2 Hose section, 10mm dia. clamp [2x]
Connect-
ing fuel line
Work step F7.
F
Installing
FuelFix
Work step F8.
Ensuring
firm seating
of FuelFix
1 Cable tie as tension relief
2 Fuel line
Securing fuel
line
96
1
2
0 mm
F 7.1.
<1... 0 mm
F 7.2.
200 min
-1
90°
50 - max
F 7.3.
F 7.4.
F 7.5.
F 7.6.
97
98
99
1
2
2
