Technical Specifications 40 Markoprint Integra Vivid
Page 9 of 45 GB
3. Technical Specifications
General
Dimensions (H x W x D in mm)
132,2 x 200,6 x 27,3 (excl. bracket and connections)
Weight integra Vivid
Weight Holder
1275g
500g
Environmental
Temperature:
5 - 40 ° C
Environmental Conditions:
10-90 % relative humidity (non-condensing)
Protection Class
IP 52
Maximum operating time
The system is designed for continuous operating
Electrical
Input voltage at the
system:
12 V – 24V DC
Connections
1x 15pin Sub-D connector
for connection to the X1JET or PP 108 print system
2x 15pin Sub-D socket
for connection of power, sensor, encoder,...
Optional:
Lead 15pin Sub-D
40006870 15pin connection cable - 2m
40006871 15pin connection cable - 5m
