Daily Repair and Maintenance
Adjust one nut at the right side of back of plaorm boom n, adjust the gap
between plaorms and nozzle, unl A4 paper has slight friconal resistance in
sliding. Aer well adjusted, press buon “OK” to enter next step.
Adjust one nut at the le side of back of plaorm boom n, adjust the gap
between plaorms and spray head, unl A4 paper has slight friconal
resistance in sliding. Aer well adjusted, press buon “OK” to enter next step.
Adjust three nuts at the boom of plaorm in synchronizaon, adjust the gap
between plaorms and spray head, unl A4 paper has slight friconal
resistance in sliding. Aer well adjusted, press buon “OK” to enter next step.
Adjust left one thumb
nuts until nozzles touch,
press OK
Adjust right one thumb
nuts until nozzles touch
press OK
