10.4.4 Control Configuration
The control configuration encompasses all the reference settings of the controllers, limiters and start ramp.
Reference voltage set (MTVC mode): _______________
Reference excitation current set (MECC mode): _______________
Reactive power reference set (MRPC mode): _________________
Power factor reference set (MPFC mode): __________________
Maximum setting of the voltage reference (MTVC mode): ________________
Minimum setting of the voltage reference (MTVC mode): ________________
Maximum setting of the excitation current reference (MECC mode): ________________
Minimum setting of the excitation current reference (MECC mode): ________________
Internal follower of the MECC mode: ____________
Maximum setting of the reactive power reference (MRPC mode): ____________
Minimum setting of the reactive power reference (MRPC mode): ____________
Maximum setting of the delayed power factor reference (MPFC mode): ____________
Maximum setting of the advanced power factor reference (MPFC mode): ____________
Initial level of the soft starter ramp: ____________
Ramp time: ___________
Knee-point frequency of U/F limiter: ______________
Slope of curve for the U/F limiter: ________________
If the excitation overcurrent limiter (LEOC) is active, configure the levels and time to actuation.
LEOC High level: __________________
LEOC Low level: __________________
LEOC Time to actuation: ___________________
If the excitation undercurrent limit is active, configure the PxQ protection curve according to the capability curve
specified by the machine.
Maximum reactive power to set the curve: ______________
Minimum reactive power to set the curve: ______________
Maximum active power to set the curve: ______________
Minimum active power to set the curve: ______________
