Technical Specifications .
74 | ECW500
12 TECHNICAL SPECIFICATIONS
12.1 POWER DATA
POWER SUPPLY
ALTERNATE
VOLTAGE
■ Maximum 242 Vac three phase or single phase, line voltage.
■ Recommended: 1,73 x V
Exc_Rated
(excitation rated voltage)
5
.
■ Frequency from 30 Hz to 500 Hz.
DIRECT
VOLTAGE
6
■ Up to 325 Vdc.
DRIVING
POWER
■ For three phase supply, 1,63 x output power.
■ For single phase supply, 1,94 x output power.
OUTPUT
CURRENT
■ Rated: 20 A @ 110 Vdc.
■ Maximum: 30 A @ 210 Vdc, during 1 minute.
■ Measurement range: from 0,5 A to 35 A.
■ Maximum error of measurement: ±5%
VOLTAGE
■ Maximum: 1,35 x V
L
(line voltage), for three phase supply.
■ Maximum: 0,90 x V
L
(line voltage), for single phase supply.
■ Commutation frequency: 2 kHz.
IMPEDANCE
FOR THE LOAD
■ Minimum resistance: 7 Ohms.
DISSIPATED
POWER
■ Maximum 2200 W.
ENVIRONMENTAL
CONDITIONS
TEMPERATURE
■ Operation: -40°C to 50°C (-40 to 122 F)
■ Storage: -40°C to 85°C (-40 to 185 F)
AIR RELATIVE
HUMIDITY
■ 10 to 90%, non condensing.
ALTITUDE
■ 0 to 1000m: rated conditions.
■ 1000 to 4000m: 1% current derating to each 100m above 1000m.
POLUTION
DEGREE
■ Degree 2, according EN50178 and UL508C.
MECHANICS
PROTECTION
DEGREE
■ IP20.
5
Example: for V
Exc_Rated
=32 Vdc, the excitation voltage must be at least 55 Vac. However, values much higher than that may worsen the
dynamic response.
6
The auxiliary DC input for excitation allows a machine without enough remanent voltage to be controlled when the power supply comes
from the machine terminals. The origin source must be galvanically isolated from the power supply.
