WEG ECW500 - 1 Quick Parameter Reference

Quick Parameter Reference
ECW500 | 1
1 QUICK PARAMETER REFERENCE
Version: V1.3X
Responsible:
Date: / /
Modbus
Address
Description
Adjustable Range
Factory
Setting
Setting
Proper
.
COMMANDS
0
0
Start excitation command
0 = Off, 1 = On
0
1
Stop excitation command
0 = Off, 1 = On
0
4
Automatic mode command
0 = Off, 1 = On
0
5
Manual mode command
0 = Off, 1 = On
0
6
Enable online command
0 = Off, 1 = On
0
7
Disable online command
0 = Off, 1 = On
0
8
Enable parallel command
0 = Off, 1 = On
0
9
Disable parallel command
0 = Off, 1 = On
0
11
Alarm reset command
0 = Off, 1 = On
0
18
Autotuning start command
0 = Off, 1 = On
0
19
F1 key command
0 = Off, 1 = On
0
20
F2 key command
0 = Off, 1 = On
0
STATUS
10000
ECW500 status
0 = Off, 1 = On
0
RO
10001
Running startup ramp
0 = Off, 1 = On
0
RO
10002
LUF Status
0 = Off, 1 = On
0
RO
10003
LEOC Status
0 = Off, 1 = On
0
RO
10004
LEUC Status
0 = Off, 1 = On
0
RO
10005
LTOC Status
0 = Off, 1 = On
0
RO
10006
DI Start status
0 = Off, 1 = On
0
RO
10007
DI Stop status
0 = Off, 1 = On
0
RO
10008
DI Increment status
0 = Off, 1 = On
0
RO
10009
DI Decrement status
0 = Off, 1 = On
0
RO
10010
DI MTVC status
0 = Off, 1 = On
0
RO
10011
DI MECC status
0 = Off, 1 = On
0
RO
10012
DI Enable Online status
0 = Off, 1 = On
0
RO
10013
DI Disable Online status
0 = Off, 1 = On
0
RO
10014
DI Enable Parallel status
0 = Off, 1 = On
0
RO
10015
DI Disable Parallel status
0 = Off, 1 = On
0
RO
10016
DI Pre-Position status
0 = Off, 1 = On
0
RO
10017
DI Reset Alarm status
0 = Off, 1 = On
0
RO
10018
DI Backup status
0 = Off, 1 = On
0
RO
COMMUNICATION
RS-485 / RS-422
30002
Serial port full duplex
0 = Disabled, 1 = Enabled
0
30006
Baud rate of the serial port
0 = 9600 bps
2
1 = 19200 bps
2 = 38400 bps
3 = 57600 bps
4 = 115200 bps
30008
Serial port parity
0 = None
0
1 = Odd
2 = Even
30010
Serial port stop bits
1 to 2
1
30012
Modbus ID
1 to 254
1
