5
DETAILED PARAMETER DESCRIPTION
P1143 - Measured inverter output voltage
Acesso: Menu → Status → Measurements → Voltage
Description:
It indicates the effective valueof the voltage at inverter output, in kV.
P1144 - Voltage between the virtual neutral of the motor and the ground of the system
Acesso: Menu → Status → Measurements → Voltage
Description:
It indicates the value of the voltage between the virtual motor neutral and the ground (GND) of the inverter, as
a percentage of the nominal effective phase voltage of the inverter.
Refer to P0296 (To obtain the value in volts, multiply by P0296/
√
3).
P1155 - Phase U cell status U1 ... Un
P1156 - Phase V cell status V1...Vn
P1157 - Phase W cell status W1...Wn
Acesso: Menu → Status → Inverter → Status
Description:
It indicates the state of the cells, by means of letters A (Active) and B (Bypass).
It indicates the state in the following order:
U1, U2, ..., Un
V1, V2, ..., Vn
W1, W2, ..., Wn
The number of cells is variable and depends of:
– P0296 (Inverter rated voltage)
– P1565 (Number of redundant cells per phase)
– P1892 (Cells in parallel)
Refer to P0296 (Inverter rated voltage) and the Table 3.1 of the user’s manual.
P1350 - Temperature on the board of cell U1
P1351 - Temperature on the board of cell U2
P1352 - Temperature on the board of cell U3
P1353 - Temperature on the board of cell U4
P1354 - Temperature on the board of cell U5
P1355 - Temperature on the board of cell U6
P1356 - Temperature on the board of cell U7
P1357 - Temperature on the board of cell U8
P1358 - Temperature on the board of cell U9
P1359 - Temperature on the board of cell U10
P1360 - Temperature on the board of cell U11
P1361 - Temperature on the board of cell U12
Acesso: Menu → Status → Measurements → Temperature
Description:
It indicates the temperature on the control board, in degrees Celsius (°C), of the respective cell.
MVW3000 | 5-102
