5
DETAILED PARAMETER DESCRIPTION
✓
NOTE!
This parameter can be changed only with the motor stopped.
P1712 - Bypass of the cell V1
P1713 - Bypass of the cell V2
P1714 - Bypass of the cell V3
P1715 - Bypass of the cell V4
P1716 - Bypass of the cell V5
P1717 - Bypass of the cell V6
P1718 - Bypass of the cell V7
P1719 - Bypass of the cell V8
P1720 - Bypass of the cell V9
P1721 - Bypass of the cell V10
P1722 - Bypass of the cell V11
P1723 - Bypass of the cell V12
Adjustable range: 0 to 4 Factory setting: 0
Acesso: Menu → Configurations → Functions → Bypass
Description:
It defines whether the respective cell should be removed from the system (option > 0).
The option 1 should be used when the corresponding cell is replaced by a mechanical bypass cell.
Option 2 must be used to manually actuate the automatic bypass relay of the cell.
Option 3 is read-only. Indicates that the respective cell was automatically removed from operation due to a
manageable fault.
Option 4 is read-only. Indicates that the respective cell was automatically removed from operation, because it
was linked in parallel (P1892) with another cell that was bypassed.
Once the parameter is set to 1, 2, 3 or 4, the respective cell can operate again as soon as the user resets the
parameter to 0 (Disable).
Refer to P1500 (Automatic Bypass).
WARNING!
Option 1 must be used after the user has physically verified that the cell in question is assembled in
the set and that it has the bypass system.
Table 5.78: Bypass of the cell V12
P1723 Function
0
Disable
1
Mechanical bypass cell
2
Manual activation of the bypass relay
3
Automatic bypass after a manageable fault
4
Automatic bypass by parallel association
✓
NOTE!
This parameter can be changed only with the motor stopped.
MVW3000 | 5-110
