QUICK REFERENCE OF PARAMETERS AND FAULTS
Param. Description Adjustable range Factory
setting
Page
P0514 On-line Graphic Function Parameter 3
Selection
0 = Inactive
1 = Motor speed reference
2 = Motor speed
3 = Motor Current
4 = Reserved
5 = Motor Frequency
6 = Output voltage
7 = Motor Torque
8 = Inverter output power
9 = Value of process variable (PID)
0 5-84
P0515 On-line Graphic Function Parameter 4
Selection
0 = Inactive
1 = Motor speed reference
2 = Motor speed
3 = Motor Current
4 = Reserved
5 = Motor Frequency
6 = Output voltage
7 = Motor Torque
8 = Inverter output power
9 = Value of process variable (PID)
0 5-84
P0516 Full scale of online graphic 1 0 to 200 % 100 % 5-84
P0517 Full scale of online graphic 2 0 to 200 % 100 % 5-84
P0518 Full scale of online graphic 3 0 to 200 % 100 % 5-84
P0519 Full scale of online graphic 4 0 to 200 % 100 % 5-84
P0520 PID proportional gain 0.000 to 7.999 1.000 5-85
P0521 PID integral gain 0.000 to 9.999 1.000 5-85
P0522 PID differential gain 0.000 to 9.999 0.000 5-85
P0523 PID ramp time 0.0 to 999.0 s 3.0 s 5-85
P0524
(1)
PID feedback selection 0 = P0237 - AI2 signal function
1 = P0241 - AI3 signal function
0 5-86
P0525 PID regulator setpoint 0.0 to 100.0 % 0.0 % 5-86
P0526 Process variable filter 0.0 to 16.0 s 0.1 s 5-87
P0527 Error Value Inv 0 = No
1 = Yes
0 5-87
P0528 Process variable scale factor 0 to 9999 1000 5-88
P0529 Process Variable Decimal Point 0 to 3 1 5-88
P0533 Process variable X value 0.0 to 100.0 % 90.0 % 5-88
P0534 Process variable Y value 0.0 to 100.0 % 10.0 % 5-88
P0535 Output N = 0 PID 0 to 100 % 0 % 5-88
P0536 P0525 Automatic Setting 0 = Inactive
1 = Active
0 5-89
P0622 End frequency of boost I x R 0 to 9999 4095 5-89
P0629 Synchronism time 1.0 to 20.0 s 1.0 s 5-90
P0630 Synchronism timeout 20 to 240 s 60 s 5-90
P0631 DI13 delay 0 to 3000 ms 170 ms 5-90
P0632 Maximum phase error 0 to 9999 1966 5-90
P0636 Phase adjustment synchronous transfer -32768 to 32767 0 5-90
P0652 MVC3 AO1 Funct. 0 to 511 2 5-91
