QUICK REFERENCE OF PARAMETERS AND FAULTS
Param. Description Adjustable range Factory
setting
Page
P0653 Analog output gain AO1 MVC3 0.000 to 9.999 1.000 5-91
P0654 MVC3 AO2 Funct. 0 to 511 5 5-92
P0655 Analog output gain AO2 MVC3 0.000 to 9.999 1.000 5-92
P0656 MVC3 AO3 Funct. 0 to 511 2 5-92
P0657 Analog output gain AO3 MVC3 0.000 to 9.999 1.000 5-93
P0658 MVC3 AO4 Funct. 0 to 511 5 5-93
P0659 Analog output gain AO4 MVC3 0.000 to 9.999 1.000 5-94
P0663 Analog output offset AO1 MVC3 -32768 to 32767 -90 5-94
P0664 Analog output offset AO2 MVC3 -32768 to 32767 -90 5-94
P0665 Analog output offset AO3 MVC3 -32768 to 32767 -90 5-94
P0666 Analog output offset AO4 MVC3 -32768 to 32767 -90 5-94
P0721
(1)
Analog input AI5 function 0 = P221/P222 0 5-95
P0722 Analog input AI5 gain (bipolar isolated
MVC4 board)
0.000 to 9.999 1.000 5-95
P0723
(1)
Analog input AI5 signal type 0 = 0-10V/20mA
1 = 4 - 20 mA
2 = 10V/20mA-0
3 = 20 - 4 mA
0 5-95
P0724 Analog input AI5 offset (bipolar isolated
MVC4 board)
0.0 to 100.0 % 0.0 % 5-95
P0725 Minimum coasting time 0 to 300 s 0 s 5-96
P0740 Function of analog input AI1 MVC3 0 = Not Used
1 = Torque reference
2 = Limit current
0 5-96
P0741 Analog input AI1 gain (bipolar MVC3
board)
0.000 to 9.999 1.000 5-96
P0742 Analog input AI1 offset (bipolar MVC3
board)
-100.0 to 100.0 % 0.0 % 5-96
P0744 Function of analog input AI2 MVC3 0 = Not Used
1 = Field current
0 5-96
P0745 Analog input AI2 gain (bipolar MVC3
board)
0.000 to 9.999 1.000 5-97
P0746 Analog input AI2 offset (bipolar MVC3
board)
-100.0 to 100.0 % 0.0 % 5-97
P0950
(1)
Motor Type 0 = Induction motor
1 = Reserved
2 = Brushless synchronous motor
0 5-97
P0957 Direction of rotation of the speed sensor 0 = Reverse
1 = Direct
1 5-97
P1000 DC link voltage of cell U1 Read-only parameter (V) - 5-98
P1001 DC link voltage of cell U2 Read-only parameter (V) - 5-98
P1002 DC link voltage of cell U3 Read-only parameter (V) - 5-98
P1003 DC link voltage of cell U4 Read-only parameter (V) - 5-98
P1004 DC link voltage of cell U5 Read-only parameter (V) - 5-98
MVW3000 | 1-23
