Wega MyConcept EVDP 2GR User Manual

52 of 76
TECHNICIANS manual
10.4.3 Technical data
Model V M L XL
Connection type 3/8" 3/8" 3/8" 3/8"
Water supply pressure
min.-max (bar)
2-8 2-8 2-8 2-8
Water temperature
min.-max. (°C)
4-30 4-30 4-30 4-30
Ambient temperature
min.-max. (°C)
4-40 4-40 4-40 4-40
Total height (A)
without bracket (mm)
420 475 500 500
Total height (B) with
the bracket (mm)
445 500 530 530
Connection (C) height
(mm)
370 425 450 450
Distance from the oor
(D) (mm)
65 65 65 65
Filter head width (E)
(mm)
125 125 125 125
Filter cartridge
diameter (F) (mm)
115 130 145 145
Weight (kg)
(empty/with water)
2.1/3.2 2.4/4.2 3.4/5.9 3.8/6.0
Replace the water lter cartridge at the frequency indicated by
the manufacturer.
E
F
B
C
D
A
For the water lter use and maintenance, follow the indications
by the manufacturer.
