TECHNICIANS manual
17. HYDRAULIC DIAGRAM
S
E
4
8
9
1
3
2
2
10
13 13
14
1615 17
18
18
18
18
20
20
22
23
24
18
20
20
2520
26
27
29
28
6 7
21 21
19
20
20
18 18
1615 17
5
12
19
14
11 12 11
30
1
TEA release
2
STEAM release
3
TEA MIX adjustment solenoid valve
4
HOT WATER solenoid valve
5
STEAM boiler safety pressure switch
6
BOILER LEVEL probe
7
SAFETY LEVEL probe
8
SAFETY valve
9
STEAM boiler
10
STEAM boiler heating element
11
COFFEE boiler
12
COFFEE water heating element
13
COFFEE water pressure switch
14
DISPENSING group
15
GROUP lter
16
GROUP Gigleur
17
GROUP solenoid valve
18
MANUAL tap
19
COLD Gigleur
20
MAINS lter
21
VOLUMETRIC dispenser
22
SCNR valve
23
PUMP pressure transducer
24
BOILER FILLING solenoid valve
25
MAINS dispenser
26
DRAIN pad
27
BUILT-IN motor pump
28
MOTOR PUMP pressure adjustment
29
WATER INLET connection
30
Softener
31
STEAM boiler NTC probe
E
Water inlet
S
Water discharge
