19 of 76
TECHNICIANS manual
ENGLISH
5.2 DPI characteristics
During installation of the machine, the following PPE
are required:
Mandatory use of protective gloves
Mandatory use of eye protection
Mandatory use of protective shoes
5.3 Environmental conditions
5.3.1 Room temperature
The electrical and electronic equipment mounted
on the machine, has been designed and made to func-
tion properly in environments where the temperature is
between +5 and +40 °C.
5.3.2 Relative humidity
The electrical and electronic equipment mounted on
the machine, has been designed and made to function
properly in environments where relative humidity does
not exceed 50% at a temperature of 40 °C, or 90% at a
temperature of 20 °C.
5.4 Installation space and operating space
Before the arrival of the machine, a suitable environ-
ment must be prepared:
• Location suited to the intended use and adequate
space for comfortable use of the machine;
• adequate lighting, in accordance with applicable
standards;
• earthing system
compliant with applicable standards
;
• electrical system compliant with applicable standards.
5.5 Support base
To ensure a sucient degree of ergonomics and safety
to the machine, it is necessary to provide a support base
with the following characteristics (refer to the drawing
on the next page):
• Make sure that there is sucient space for placing
and correctly using the machine.
• the base (1) should be comfortable and suitable for
supporting the weight of the machine and a height
of about 90 cm (17);
• the base must be perfectly level and without irregu-
larities;
• The base must be in close proximity to the terminals
for the connection to the water mains (11) and to the
power supply (8);
• If the machine is positioned next to a wall, ensure a
minimum distance of 20 cm between the machine
and the wall (3).
• equip the working base of the machine with a drawer
(15) for used coee grounds, preferably with a rubber
device (16) for tapping the lter holder.
For correct operation and to ensure safety, the machine must rest
on a perfectly horizontal surface.
Any alignment of the machine must be done by adjusting the
feet (7).
In case of installation of the machine within moving environments
(trains, ships, etc.) it is necessary to use special anchor pins, which
can be bought from the manufacturer, to the base.
