58 of 76
TECHNICIANS manual
10.7.6 Perforated disk and containment ring cleaning
Weekly perform the cleaning
of the Perforated disk and con-
tainment ring in the following
way:
• Loosen the screw (3);
• remove the perforated disk
(2) and the containment ring
(1);
• carefully wash the two com-
ponents with hot water;
• replace perforated disk and
containment ring to its origi-
nal position by locking every-
thing with the screw.
10.7.7 Steam nozzle/Autosteamer cleaning
Daily perform the cleaning of the Perforated disk and
containment ring in the following way:
• Immerse the spout in a jug with water and a specic
detergent according to manufacturer's instructions;
• heat the solution with the steam of the spout;
• let the spout cool o keeping it
immersed in the solution for at
least 5 minutes to allow the de-
tergent to rise inside the spout by
cooling eect;
• repeat the operation 2 or 3 times
until milk is delivered.
1
2
3
11. SPARE PARTS
For the replacement of components and/or parts of
the machine, refer to the ocial documentation provided
by the Manufacturer.
On the internet site of the Manufacturer all original spare parts
are available. The Manufacturer may provide the list of spare
parts recommended for the maintenance of the various versions
of the machine.
In case of use of parts that are not original, the safety of the
machine cannot be guaranteed.
The Manufacturer reserves the right to void the machine warranty.
