Wega MyConcept EVDP 2GR - Machine description

8 of 76
TECHNICIANS manual
2.4 Machine description
1. Illuminated side edge.
2. Steam knob.
3. Cool touch steam spout (*).
4. Hot water nozzle
5. ON switch
6. Adjustable foot.
7. Pull-out cup support grille.
8. Filter holder.
9. Dispensing compartment LED light
10. Display touch screen.
11. Cup-rest grid
12. USB socket.
13. Cup heater surface.
(*) Autosteamer nozzle (optional).
The USB port (12) must only be used with the specic stick provided
to Qualied Technicians. Do not connect external devices (iPhone,
iPad, PC, etc.) to the USB port because it could create serious
problems in the machine software.
