TECHNICIANS manual
ENGLISH
Fuse Description
F1 Fuse 5x20 delayed, 6.3A Protects: from RL1 to RL13
F2 Fuse 5x20 FF super rapid, 10A Protects: group coee boiler heating element 4
F3 Fuse 5x20 FF super rapid, 10A Protects: group coee boiler heating element 2
F4 Fuse 5x20 FF super rapid, 10A Protects: group coee boiler heating element 3
F5 Fuse 5x20 FF super rapid, 10A Protects: group coee boiler heating element 1
F6 Fuse 5x20 FF super rapid, 10A Protects : coee boiler heating elements, group 1 and 3
F7 Fuse 5x20 delayed, 1A Protects: transformer's double winding
F8 Fuse 5x20 FF super rapid, 10A Protects : coee boiler heating element group 2 and 4
F9 Fuse 5x20 delayed, 1A Protects: services boiler heating element group 1 and 2
F11 Fuse 5x20 delayed, 125mA Protects: transformer +12Vac
LED Description
DL1 Front Led
DL2 Side Led
DL3 Cup heater
DL4 Heating element control boiler group 4
DL5 Heating element control boiler group 2
DL6 Heating element control boiler group 3
DL7 Heating element control boiler group 1
DL8 group 1 heating element
DL9 group 3 heating element
DL10 group 2 heating element
DL11 group 4 heating element
DL12 services 1 boiler heating element
DL13 group 4 volumetric counter
DL14 group 3 volumetric counter
DL15 group 2 volumetric counter
DL16 group 1 volumetric counter
DL17 services 2 boiler heating element
DL18 Inlet volumetric counter
DL20 CN45 connection
DL21 Display connection
DL22 Display connection
DL23 Communication RS232 CN13
+5V +5V Power supply
+9V +9V Power supply
+12V +12V Power supply
+24V +24V Power supply
Relay Description
RL1 Pump
RL2 Solenoid valve group 1
RL3 Solenoid valve group 3
RL4 Solenoid valve group 2
RL5 Solenoid valve group 4
RL6 Boiler lling solenoid valve
RL7 Hot water mix solenoid valve
RL8 Tea solenoid valve 1
RL9 Autosteamer steam solenoid valve
RL10 Side LED solenoid valve
RL11 Air solenoid valve
RL12 Tea solenoid valve 2
RL13 Front LED solenoid valve
Conn. Description
CN1 Heating element connection 1 - 3 GR
CN2 Heating element connection 2 - 4 GR
CN3 Services boiler heating element connection
CN4 Connection of coee boiler pressure switches
CN5 Volumetric dispenser and services boiler level connection
CN13 RS232 serial socket connection
CN15 Coee boiler pressure NTC connection
CN16 Mains pressure, humidity sensor and boiler press. transducer supply
CN17 Connection of NTC services boiler
CN18 Connection of NTC Autosteamer
CN19 Connection of NTC cup heater
CN22 Wiring of circuit board
CN23 Connection of 230V AC outputs
CN24 Connection of 230V AC outputs
CN25 Boiler heating element connection 2 - 4 GR
CN26 Boiler heating element connection 1 - 3 GR
CN41 Display TFT cable connection
CN42 Level probe connection.
CN43 WiFi module connection
CN45 Not used.
CN46 USB drive connection
Jumper Description
SW3 Micro factory programming
SW5 485 CN45 activation not used
JP6 Serial power management: 1-2=+12V 2-3=+5V
