Wega WBAR EVD User Manual

TECHNICIANS' manual
- English -
35 di 52
7.5.3 Technical data
Model V M L XL
Connection type 3/8" 3/8" 3/8" 3/8"
Min.-max. water
supply pressure
(bar)
2-8 2-8 2-8 2-8
Min. - max. water
temperature (°C)
4-30 4-30 4-30 4-30
Room temperature
min-max (°C)
4-40 4-40 4-40 4-40
Total height (A)
without bracket
(mm)
420 475 500 500
Total height (B)
with the bracket
(mm)
445 500 530 530
Connection (C)
height (mm)
370 425 450 450
Distance from the
floor (D) (mm)
65 65 65 65
Filter head width
(E) (mm)
125 125 125 125
Filter cartridge
diameter (F) (mm)
115 130 145 145
Weight (kg)
(empty/with water)
2.1/3.2 2.4/4.2 3.4/5.9 3.8/6.0
Replace the water filter cartridge at the frequency in-
dicated by the manufacturer.
E
F
B
C
D
A
To use and maintain the water filter, follow the indi-
cations by the manufacturer.
