TECHNICIANS' manual
- English -
22 di 52
5.4 Installation and operation spaces
Before the machine arrives, a suitable environment must be
prepared:
• The appliance is not suitable for installation in an area
where a water jet may be used.
• The machine is not suitable for outdoor use.
• The machine must not be used inside kitchens.
• The room must be suited for the intended use with ade-
quate space to comfortably use the machine.
• The lighting must be adequate and conform with current
standards.
• The earthing system must comply with current standards.
• The electrical system must comply with current regula-
tions.
5.5 Support base
To ensure a sucient degree of ergonomics and machine safe-
ty, a support base with the following features must be made
available (reference drawings on the next page):
• Ensure that there is sucient space for the machine to be
positioned and used correctly.
• The worktop (40) must be comfortable and able to with-
stand the machine’s weight. The height of the upper sec-
tion of the machine (54) must be at least 150 cm from the
floor.
• The base must be perfectly level and have no irregularities.
• The terminals for connecting to the water mains (51) and
electrical mains (46) must be in the immediate vicinity of
the support base.
• The machine can also be positioned against a wall, but
please leave enough space - at least 50 cm (42) - on the
right and left for easy access during cleaning operations.
• Fit a drawer under the worktop (52) which will be used to
deposit used coee grounds and if possible, also fit a rub-
ber support (53) to knock the filter holder against.
FOR THE USA: Replace the machine’s feet (45) with
the raised ones supplied.
The new feet must be firmly fastened to the machine
by means of the specific nut.
In order to work properly and ensure safety, the ma-
chine must rest on a perfectly horizontal surface.
Any machine alignment adjustments must be carried
out by adjusting the feet (45).
42
42
54
40
41
53
45
46
44
43
47
48
49
50
51
52
