WEIGHTECH USA Weighing indicator WT3000-IR ABS– Technical manual
Wt3000irabs v20151126
15
FnC-03
Check
weight
configuration
000.00h
Upper weight limit
000.00h
000.00L
Lower weight limit
000.00L
000.00b
1
a
1
b
1
c.
00b
a
1 → Beep on
0 → Beep off
b
1 → Beep sounds when weight is stable.
0 → Beep sounds when weight is unstable.
c
1 → Beep sounds when the weight applied is between
upper and lower limits.
0 → Beep sounds when the weight applied is 10d or
more over the upper limit and 10d under the lower limit.
000.00b
FnC-04
Unused
parameter.
---.---
Unused parameter.
---.---
Fnc-05
Filters
ZEro 0
After reaching 1/3 of the maximum load, the indicator will forces the
return to zero when the weight applied is removed.
ZEro 0
FiL 0
Stability filter from 0 to 9
Higher the value, more stable the weight show.
FiL 0
3db 5
Digital filter from 0 to 9
Higher the value, faster is the response of the indicator
3db 5
Fnc-06
Hold function
hoLd 0
Hold function disabled
hoLd 0
hoLd 1
Peak detection.
To reset the function remove the weight applied and press any
key.
hoLd 2
Freezes the weight show on the display when stable.
To reset the function remove the weight applied and press any
key.
hoLd 3
Freezes the weight show on the display when stable.
The function will resets when the weight applied is less than
10d.
hoLd 4
Animal weighing mode.
At zero the indicator shows "---. ---" When a load is applied, the
indicator immediately starts the calculation of the applied load,
returning to indicate "---. ---" When the measured load is less
than 10d.
After activate the animal weighing is necessary to set the
parameters for calculating the weight.
Code
Description
Factory default
010%
Range of error in
measurement.
Range 1% to 100%
010%
8
Number of samples
used to calculate
the weight.
Range 1, 2, 4, 8, 16,
32 or 64 samples.
8
hoLd 5
Animal weighing mode 2
When a load is applied the indicator immediately starts to
measure the weight value, after determine the weight value
