Weinmann Oxygen MODULE User Manual

36 Spare parts
27
Sieve set
consisting of 2 seals and 1 sieve
WM 15284
28
29
30
31
Set of fixing components
consisting of:
– O-ring 8 x 4
– Raised countersunk head screw M4 x 10 DIN 966
– Protective washer Ø 4
– Raised countersunk head screw M4 x 8 DIN 966
WM 15288
32
33
34
Set of spare parts, screws
consisting of:
– Fillister-head screw KB 30 x 20, 6 off
– Raised countersunk head screw M 3 x 6 DIN 966
– Countersunk screw M 3 x 10 DIN 965
WM 15194
35
36
37
Set of spare parts, rubber parts
consisting of:
– Blind plugs
– Rubber buffer, receptacle
– O-ring 8 x 4
WM 15266
38
39
Set of spare parts, seals
consisting of:
– Seal 7 x14 x 2
– O-ring 6 x 2
WM 15283
40 Angular bush 4/6 WM 22552
41 Swivel screw connection 2/4 WM 22588
42 Swivel screw connection for pressure gauge WM 4699
43 Straight screw-in bush WM 7526
44 Seal 5 x 8 x 1 WM 1145/64
45 Knob Ø 15 WM 4897
46 Lid, matt blue, Ø 15 WM 4899
47 Cap, chrome-plated WM 22204
48 Non-return valve, assembled WM 22232
49 Pressure screw WM 1158
50 O-ring 8-1.3 WM 1145/94
51 Counter nut WM 22226
52 Fixing nut M12 x 0.75 WM 22234
53
Service label:
– 2008
– 2009
– 2010
– 2011
– 2012
– 2013
– 2014
– 2015
WM 0498
WM 0499
WM 0300
WM 0609
WM 0610
WM 0366
WM 0301
WM 0302
Distributor block, assembled WM 22263
Loctite, 245 WM 14920
Oxygen lubricant Berulub WM 14902
Item no. Designation Order No.
