Weinmann VENTIlogic plus - Analog Box with Therapy Device

Technical data 115
EN
11.6 Analog box with therapy device
Channel Measured value Scaling
0 V 1 V
Channel 1 Mask pressure 0 hPa
VENTIlogic plus:
55 hPa,
VENTIlogic LS: 55 hPa
Channel 2 Flow -100 l/min +320 l/min
Channel 3 Leakage flow 0 l/min +320 l/min
Channel 4 Tidal volumes 0 ml 3000 ml
Channel 5 – All spontaneous respiration
modes: on inspiration
trigger
– All mandatory modes: not in
use
– All spontaneous
respiration modes: on
inspiration trigger
– All mandatory modes:
not in use
– All spontaneous
respiration modes: on
inspiration trigger
– All mandatory modes:
not in use
Channel 6 not in use not in use not in use
Channel 7 not in use – –
Channel 8 not in use – –
