11. Technical data
11.1 Therapy device
Therapy device
Product class to Directive
93/42/EEC
IIb
Dimensions W x H x D in cm 24 x 15.3 x 34
Weight approx. 5.9 kg excluding replaceable battery
approx. 6.5 kg including replaceable battery
Temperature range
– operation
– storage
+5 °C to +35 °C
–40 °C to +70 °C
Air pressure range 600 – 1100 hPa (keep leaks small below 700 hPa, as the device
may no longer be able to compensate at very high ventilation
pressures)
Electrical rating 100-230 V AC, 50-60 Hz
Tolerance -20 % +10 %
Current consumption during
– operation
– standby
230 V 100 V
0.35 A 0.8 A
0.05 A 0.13 A
Maximum power consumption 120 W
Breaking capacity of remote
alarm connection
60 V DC/2 A; 42 V AC/2 A
Internal battery
– Model
– Nominal capacity
– Nominal voltage
– Nominal output
Li-Ion
3100 mAh
39.6 V
121 Wh
Life span of internal battery
(internal and removable battery
together)
– service life for typical load cases
depending on age and ambient
temperature
Load case 1 : PEEP=0hPa, f=20/min, Ti/T=40%, R=8hPa/l/s,
C=40ml/hPa, Vt=300ml,
approx. 8.5 h (17 h)
Load case 2 : PEEP=0hPa, f=20/min, Ti/T=50%, R=5hPa/l/s,
C=50ml/hPa, Vt=800ml,
approx. 6.25 h (12.5 h)
