Weinmann VENTIlogic plus - Special Markings on the Device

12 Overview
EN
1.1 Special markings on the device
Left-hand side
1
Oxygen connection: maximum supply rate: 15 l/min at < 1000 hPa
2
VENTIlogic LS:
Opening for exhaled air when operated with double patient circuit with patient
valve; do not seal opening or block in any other way.
VENTIlogic plus:
Opening is not used with VENTIlogic plus.
7
6
5
4
3
2
1
12
11
10
9
15
18
14
16 17
8
13
