26
83055116 1/2016-05
Installation and Operating Instructions
G
as burner WG20.../1-C ZM-LN (W-FM 25)
5 Operation
5
.2.1 Info mode
Burner status and information can be retrieved in the Info mode.
u Press [Enter] for approx. 0.5 sec.
a The Info level is activated.
u Press [Enter] to reach the next information.
No. Information
0 Total gas consumption in m
3
(via X3:8)
Reset value:
uPress [L/A] and [+] simultaneously for approx. 2 sec.
1 Hours run
2 - no function -
3 Burner starts
4 Device item number
5 Index of device item number
6 Device number
7 Production date (DDMMYY)
8 Fieldbus address
9 Valve proving setting
11 Current blower speed (only with VSD)
Display of standardized speed:
uPress [L/A].
12 Current gas consumption (0.1 m
3
/h)
13 Analogue module EM3/3 - or - Fieldbus module EM3/2 available
0 = no
1 = yes
After information 13 or a waiting time of approx. 20 sec, the combustion manager
changes back to the Operating mode.
l,m³
