29
Installation and Operating Instructions
G
as burner WG20.../1-C ZM-LN (W-FM 25)
83055116 • 1/2016-05
5 Operation
5.2.4 Access mode
In the Access mode, the configuration can be adapted relative to the burner type or
version.
In the Parameter mode, the display mode must be configured to ON, in order to enable
access to parameters E0 ... E3.
u Press [G] and [L/A] simultaneously.
a The Access level is activated.
u Press [+].
a Parameter E0 is displayed
u Press [Enter] to reach the next information.
Parameters Information Range of values
E0 Burner type 0 = single fuel burner
1 = dual fuel burner
E1 Operating mode 0 = intermittent operation
(display only, no adjustment possible) 1 = continuous operation
E2 Flame sensor type 0 = ionization electrode / flame sensor FLW
1 = switch input (X3:14)
2 = flame sensor QRB
E3 Blower configuration 0 = off
1 = blower control
2 = blower control with blower monitoring
3 = not used (VSD)
4 = blower ctrl. acc. to specified modulating degree
5 = DAU control
6 ... 255 = off
