High Torque Rotary Unit • ST0055 - ST0140 • R04-2014
11/42
Product description
3.1 Structure
3
3 Product description
3.1 Structure
The optionally programmable, highly dynamic High Torque Rotary Unit consists of a solid
base body made of aluminium with the electrical connections and the rotary disc.
The machine can be certified for sterile room usage.
Every machine can be delivered in different sizes and lengths.
The existing holes in the base body allow versatile options of fixing.
Operator installations can be fixed on the rotary disc.
The electric connections are made via plug-in connections.
A absolute measuring system is used as a measuring system. The measuring system
used depends on the order.
The following parameters of the machine are variable:
• size
• length
• rotary encoder
• holding brake
Fig. 1: General view of the rotary unit
ST0075 ST0140ST0055
