High Torque Rotary Unit • ST0055 - ST0140 • R04-2014
13/42
Product description
3.3 Technical data
3
3.3.1 Scope of delivery
The scope of delivery of the machine depends on the order involved. Please refer to the
order information or order specifications for individual components.
3.3.2 Sound level
The A-weighted emission sound pressure level does not exeed the allowable peak.
3.3.3 Type plate
The type plate is fitted to the housing of the machine and contains the details described
in the illustration.
The illustrated type plate is only an example of a machine and is not
identical to the actual type plate of the described product.
A second type plate is included in the scope of delivery. The second plate can be moun-
ted at a clearly-visible location on the machine to allow viewing of performance data if the
type plate fitted by the manufacturer is concealed by any other structures.
Fig. 2: Example of a type plate
3.3.4 Ambient conditions
Additional barcode serial number
Type
Serial Number
Motor speed
Nominal torque
Rotary encoder
Year of construction
Weight
www.weiss-gmbh.de
WEISS
type
motor
serial
weight
motor
year
STXXXXXX - X
STXXXXXX
XXXXXXX
XX kg
XXXX
encoder
XXX UPM
X,X Nm
Humidity 5 % to 95 %, non-condensing
Allowable temperature range
Storage: +5 °C to +55 °C
Operation: +15 °C to +45 °C
Environment
It is not permissible to use the machine in environ-
ments that contain abrasive dusts.
