High Torque Rotary Unit • ST0055 - ST0140 • R04-2014
27/42
Installation
5.3 Assemble machine
5
5.3 Assemble machine
Different holes and thread drills are available to assemble the machine.
The existing holes and/or thread drills must be used to assemble
the machine. Additional drills or welding on the machine is prohibited. Damage to
the machine.
The machine can be assembled in the admissible installation layers at customer location
using the existing drills and/or thread drills.
1. Set up the machine at the assembly position.
2. Tighten the attachment screws however, not all the way.
3. Align the machine.
4. Tighten the attachment screws all the way.
5. Make electrical connections in accordance with the circuit diagrams.
5.3.1 Installation of additional components
To assemble the attachment parts on the rotary disc, the existing
holes and/or thread drills must be used. Additional drills or welding on the machine
is prohibited. Damage to the machine.
To guarantee concentricity and part accuracy, attachment parts may only be assembled
with the intended fitting bore resp. with centre bore and threads.
By using the existing drills and/or thread drills additional components can be mounted at
the rotary disc.
5.4 Installing the safety equipment
The operator is responsible for providing for safety equipment and emergency stop but-
tons. The machine may not be operated without suitable safety equipment.
5.5 Instructions on disposal of packaging material
Packaging materials should be reused or disposed of properly in compliance with natio-
nal regulations.
