WEISS ST Series User Manual

High Torque Rotary Unit • ST0055 - ST0140 • R04-2014
17/42
Product description
3.3 Technical data
3
3.3.6.3 High Torque Rotary Unit ST140
Measurement table: Dimensions in mm
ST
A
Sick Stegmann Heidenhain
SEK90 ECN113 ECN225
with holding brake with holding brake with holding brake
140-1 137 196,8 168 224 168 224
140-2 164,5 224,3 195,5 251,5 195,5 251,5
8x 14
H7
x5+0,1 8x M10x18
70 ±0,01
B
0
32,50 ±0,01
92,50 ±0,01
140 -
0
0,1
70 ±0,01
0
32,50 ±0,01
92,50 ±0,01
A
140
140
2x
6
H7
x10
6x M8x10
76
25,6
120 ±0,01
120 ±0,01
50
Lk 90 ±0,01
60°
30°
28 4x 14
H7
4x M10
20
5
+
0,1 0
4x M10
15
4x 15
32,5
