WEISS ST Series - Page 20

High Torque Rotary Unit • ST0055 - ST0140 • R04-2014
20/42
Product description
3.4 Electrical connections
3
3.4.2.2 ST55: Connection encoder
⇐ to the drive Pin assignment
InterContec yTec - 12-pin EEDA101MR04000001000
10
7
12
8
4
1
9
2
3
5
6
11
GND
+ 7...12V
+ SIN
+ COS
REFSIN
n.c
REFCOS
n.c
Data +
Data -
1
2
3
4
6
7
8
5
10
11
12
9
E
n.c
n.c
B
A
B
