WEISS ST Series - Page 24

High Torque Rotary Unit • ST0055 - ST0140 • R04-2014
24/42
Product description
3.4 Electrical connections
3
3.4.2.6 ST140: Connection encoder
⇐ to the drive Pin assignment
InterContec M25 D_AEGA052MR04000201000
10
7
12
8
4
1
9
2
3
5
6
11
GND
+7...12V
n.c
n.c
+COS
REFCOS
+SIN
REFSIN
Data -
Data +
n.c
n.c
1
2
9
10
P
8
7
12
6
11
3
4
5
B
B
