Directions for Use Chapter 1 Introduction 7
Controls, Indicators, and Connectors
This section describes the controls, indicators, and connectors that are part of the
electrocardiograph.
Figure 3. Top
Figure 4. Back
1
!
2
@
3
#
4
$
5
%
6
+
7
-
8
*
9
(
0
)
Softkeys and functions keys
See
Figure 8 on page 10.
Keyboard
See
Figure 1 on page 9.
AC power inlet
AC fuses
Equipotential stud
