3.6 Symbols chart
I
Power On
O
Power Off
Power On
Indication
Fault Indication
Caution / Hazard
Read Instruction
Manual
MIG Function
TIG Function
Stick/MMA
Function
Material Thickness
Wire Feed
Amperage (current)
output
Voltage output
Variable
Inductance
Increase/Decrease
Save Settings
Recall Settings
Single phase
Inverter power
source DC
MIG (GMAW)
Function
Stick/MMA
(SMAW) Function
TIG (GTAW)
Function
Power Supply
Connection
Single Phase
Direct Current (DC)
–
Negative
+
Positive
Hertz (cycles/sec)
Duty Cycle
Amperage
(Current)
Voltage
Table 4
