4.2 MIG Program Selection
(Only available in MIG process mode)
1. Press ‘P’ button (26 - MIG Program Selection Button)
2. Rotate Right Selection Knob (32) to choose program (refer to chart below)
3. Press ‘P’ button (26)
NOTE: Program ‘0’ is traditional Manual MIG mode which allows you to manually adjust volts and
wire speed.
MIG Program Chart
Program
Wire Size
Wire Type
Shielding Gas
0
Manual (Non-Synergic)
1
0.6mm
Solid Steel
Mixed (Argon + CO
2
)
2
0.8mm
3
0.9mm
4
1.0mm
5
1.2mm
6
0.6mm
Solid Steel
CO
2
7
0.8mm
8
0.9mm
9
1.0mm
10
1.2mm
11
0.8mm
Flux Cored Steel
Gasless or Gas
12
0.9mm
13
1.0mm
14
1.2mm
15
0.8mm
Stainless Steel
Mixed or Argon
16
0.9mm
17
1.0mm
18
1.2mm
19
0.8mm
Silicone Bronze (CuSi)
Argon
20
0.9mm
21
0.8mm
Aluminium
Argon
22
0.9mm
23
1.0mm
24
1.2mm
Table 5
Figure 7
2
1, 3
