7.1.1 Fitting Wire Spool – 200mm Diameter (5kg)
Follow the same procedure as for 300mm spool as above however slide the 200mm Spool Spacer
onto the Spool Post before you fit the Wire Spool. Take care to ensure that the Spool Lock Pins
are aligned.
Figure 18
200mm Spool Spacer
Spool Post
Spool nut
200mm Wire Spool
