WIKA UniTrans UT-10 User Manual

C
Universal Pressure Transmitter UniTrans
Technical Data
Published 16.2.04
Subject to change due to technical modifications. © Copyright WIKA Alexander Wiegand GmbH & Co. KG / BRD
WIKA Alexander Wiegand GmbH & Co. KG · Alexander-Wiegand-Str. · 63911 Klingenberg ·

(09372) 132 - 710 · Fax - 706 · E-mail: support-tronic@wika.de · www.wika.de
51
3.3 Construction
Inte
g
ration time 0s, 1s, 5s, 20s, 40s, pro
g
rammable
Adjustment of the span Up to Turn down 1 : 20
Inte
g
rated li
g
htnin
g
protection optional
Zero point adjustment 2.5 ... 99 %
Process connections
Model UT-10
Model UT-11
Model UT-11 EHEDG version
G 1/2 B per DIN 16288 (1/2 NPT)
M 16 x 1,5 with sealin
g
cone
>
1600 bar
3/8-24 UNF LH male
>
1600 bar
1/4"-28 UNF LH M 250-C
>
1600 bar
G 1B flush diaphra
g
m with o-rin
g
(Ran
g
es:
0 ... 0.4 up to 0 ... 1.6 bar)
G 1/2 B flush diaphra
g
m with o-rin
g
(Ran
g
es:
0 ... 6 bis 0 ... 600 bar)
G 1 1/2 flush diaphra
g
m with o-rin
g
(Ran
g
es:
0 ... 0.4 bis 0 ... 16 bar)
G 1 flush diaphra
g
m with o-rin
g
(Ran
g
es:
0...0.4 bis 0...16 bar)
G 1 flush diaphra
g
m with o-rin
g
and coolin
g
element (Ran-
g
es:0...0.4 bis 0...16 bar)
Materials
Housin
g
Wetted parts (UT-10)
(UT-11)
Internal transmission fluid
hi
g
hl
y
resistive, fiber
g
lass-enforced
plastic (PBT); optionall
y
aluminium
CrNi-steel 1.4571 and 2.4711
CrNi-steel 1.4571, o-rin
g
: NBR {Viton or
EPDM}; {Hastello
y
C4}
Standard {Halocarbon oil for ox
yg
en-
applications}; {FDA-approved}
