2.3 Installation Examples
The UniTrans is primaril
used to monitor the pressure in pipes, technical equipment
and tanks. Dependin
e pressures between 20 mbar up to 1000
bar can be measured. The pressure is measured usin
ainst a vacuum)
or relative (a
ainst external or air pressure) measurement dependin
pe of
sensor selected.
The UniTrans is also used for h
drostatic pressure measurement within liquid filled
pipes and containers.
Process Pressure Measurement: Process Pressure Measurement:
Used to measure pressure of liquids Used to measure container pressure.
or gases in pipelines.
Process Pressure Measurement: Process Pressure Measurement:
Installed behind feed pumps for Installed in front of and behind the filter.
process control or monitoring of pump Uses the pressure differential for moni-
functions. toring the function or accumulation of dirt
in the filter. Both output signals are pro-
cessed by a PLC or signal converter.
