Universal Pressure Transmitter UniTrans
Product Description
Published 16.2.04
Subject to change due to technical modifications. © Copyright WIKA Alexander Wiegand GmbH & Co. KG / BRD
WIKA Alexander Wiegand GmbH & Co. KG · Alexander-Wiegand-Str. · 63911 Klingenberg ·

(09372) 132 - 710 · Fax - 706 · E-mail: support-tronic@wika.de · www.wika.de
45
2 Product Description
The UniTrans pressure transmitter can be used in level control applications as well as
for pressure measurement applications in process industr
y
. A variet
y
of process con-
nections, measurement ran
g
es, main boards and displa
y
options result in a product
for a wide ran
g
e of applications.
2.1 Construction
The UniTrans consists of a pressure sensor, a control interface unit and a housin
g
cover with optional displa
y
. Due to this modular desi
g
n, different transmitter versions
can be mounted (see “Model Ke
y
” on pa
g
e 79).
2.1.1 Pressure Transducer
The pressure transducer has a piezo-resistive or thinfilm measurement cell depend-
in
g
on the pressure ran
g
e. The sensors are temperature compensated, and have a
hermeticall
y
welded membrane which is "helium" leak-tested. The pressure trans-
ducers do not have internal sealin
g
elements.
Pressure transducers further distin
g
uish themselves from one another based on their
pressure ran
g
es and the different materials of wetted parts. Different process
connections can be selected to serve a wide ran
g
e of applications.
Never exceed the overpressure limit of the respective pressure transducer.
Direct Mounted
Processing Unit Housing
Attention
