External dosing devices
18
17 External dosing devices
Instead of the integral dosing device, external dosing devices can also be used. Follow the instructions in
this section.
17.1 Terminals
Danger
Danger to life. Live components.
Have the dosing device installed and commissioned by an authorised service technician.
1
Detergent dosing nipple
2
Transfer strip for the connection of external dosing devices
3
Rinse aid dosing nipple
4
Circuit diagram
INFO On the right side of the machine, there are bushings for cables and hoses.
