1139300 Shadow 8 User Manual
2-2 Installation and Checkout
Installing Shadow 8 is a straightforward procedure. However, you must install the unit with
care since Shadow 8 is a safety device that protects press operators and other personnel.
Before proceeding, make sure that you received the following items in your Shadow 8 order:
• Two optic heads (Main Transmitter and Main Receiver)
• A remote control box (if included in order)
• Two quick-disconnect cables, one for each optic head (required cable lengths specified at
time of order).
• Extension heads and interconnect cables (if included in order)
If any of these components is missing, contact Wintriss Tech. Support before starting installation.
Calculating the Safety Distance
Instructions must be followed exactly for proper installation of Shadow 8.
OBSERVE THE CORRECT SAFETY DISTANCE
• Calculate the safety distance carefully, following the instructions below, and mount your light
curtain heads at least the calculated distance from the hazardous area.
• Mount your light curtain heads at least 7.5 in. (191 mm) from the hazardous area regardless of
the calculated safety distance.
Failure to comply with these instructions will result in death or serious injury.
OBSERVE CORRECT SAFETY DISTANCE WHEN USING FIXED OR FLOATING BLANKING
• Read Increasing Safety Distance To Compensate for Blanking Windows, page 2-10 before
calculating the safety distance. This section explains how to modify the safety distance when
you use programmable fixed blanking or floating blanking windows.
• Modify the calculated safety distance as required.
Failure to comply with these instructions will result in death or serious injury.
