Wintriss Shadow 8 - Figure 2-19. Shadow 8 Control Box: Mounting Dimensions

1139300 Shadow 8 User Manual
2-30 Installation and Checkout
Figure 2-19. Shadow 8 Control Box: Mounting Dimensions
P
R
O
G
R
U
N
S
T
A
R
T
OSSD 1
OSSD 2
POWER
O
F
F
P
R
O
G
O
N
0.30
(7.6)
8 places
Dimensions:
inches
(mm)
10.80
(274.3)
10.10
(256.5)
9.60
(243.8)
7.43
(188.6)
6.55
(166.4)
4.00
(101.6)
2.05
(52.1)
3.89
(98.7)
3.24
(82.2)
2.76
(70.1)
