Wittenstein LUC+125 - Technical Data

Lubricator Operating manual
Revision: 02
2022-D064493
en-8
3.4 Technical data
Housing
Dimensions with 125
cm³ cartridge
(W x H x D)
83 x 152 x 83 mm
Dimensions with 250
cm³ cartridge
(W x H x D)
83 x 190 x 83 mm
Weight (without lubricant) approx. 350 g
Mounting possibilities Rear side 2 x M5
Underside 1 x M5 and/or G1/4"
Torque M5 3 Nm
Mounting position arbitrary, preferably vertical
Permissible operating temperature -20 °C to +70 °C
Material PA 6.6 GF 30 / POM
Lubricants
Cartridge volume 125 cm³ / 250 cm³
Lubricant type Grease up to NLGI Class 3, solid contents possible
Hydraulic data 24V Version Battery Version
Number of outlets 1 1
Thread of outlet G1/4" and M6 G1/4" and M6
Number of lubrication points up to 4 in conjunction with
splitter
up to 14 in conjunction with
progressive distributor
up to 4 in conjunction with
splitter
up to 10 in conjunction
with progressive distributor
Hydraulic connection Direct or via additional tube
connection to PA tube
Direct or via additional tube
connection to PA tube
Max. pressure 12 or 50 bar (adjustable) 12 or 35 bar (adjustable)
Dosing volume/stroke 0.15 cm³ 0.15cm³
Number of pump strokes per
cartridge
approx. 830 (with 125 cm³) /
approx. 1660 (with 250 cm³)
apprx. 830 (with 125 cm³)
Electrical data 24V Version Battery Version
Display LCD LCD
Operating voltage 24 V DC (external) +/- 5 % 4.5 V
Current input Imax < 300 mA
standby current < 25 mA
-
Fuse 750 mA, slow-blow -
Connecting plug M12x1, 4-pole M12x1, 4-pole
Protection class IP 54 IP54
